RTD Thin Film
Heraeus
Specification: DIN EN 60751 (according to IEC 751)
Temperature range: -70°C to +500°C (continuous operation)
Leads: Platinum coated nickel wire; Lead length: 10mm ±1mm
Insulation resistance: > 100 MΩ at 20°C; > 2 M Ω at 500°C
Accuracy class: F0.10 (Class 1/3B); F0.15 (Class A); F0.30 (Class B)
IST
Specification: DIN EN 60751 (according to IEC 751)
Leads: Platinum coated nickel wire, with diameter 0.2mm
Lead length: 10mm ±1mm
Accuracy class: F0.10 (Class 1/3B); F0.15 (Class A); F0.30 (Class B)
Hayashidenko
Specification: DIN EN 60751 (according to IEC 751)
Leads: Gold plated nickel wire; Lead length: 10mm ±1mm
Accuracy class: F0.10 (Class 1/3B); F0.15 (Class A); F0.30 (Class B)
Typical dimensions: 2.0x5.0x1.0mm
Temperature range: -70°C to +500°C
